Pipe Junction Solution Direction

The methods in this category are used to control the available dispatch methods and therefore which direction the pipe junction is solving. The none default methods may be selected in Rulebased Simulation when you need to control this direction.

Solve Flow 1, Flow 2, or Flow 3

This is the default method and should remain selected for basic simulation. There are no slots or calculations specifically associated with this method. It simply allows all dispatch methods to be active.

Solve Flow 1 or Flow 2 Only

This method may need to be selected in Rulebased Simulations if the Pipe Junction is solving in one direction only. When this method is selected, only the Solve given Flow 2, Flow 3 or Solve given Flow 1, Flow 3 dispatch methods are available.

Solve Flow 1 Only

This method may need to be selected in Rulebased Simulations if you want the Pipe Junction to solve in one direction only. When this method is selected, only the Solve given Flow 2, Flow 3 dispatch method is available.

Solve Flow 2 Only

This method may need to be selected in Rulebased Simulations if you want the Pipe Junction to solve in one direction only. When this method is selected, only the Solve given Flow 1, Flow 3 dispatch method is available.

Solve Flow 3 Only

This method may need to be selected in Rulebased Simulations if you want the Pipe Junction to solve in one direction only. When this method is selected, only the Solve given Flow 1, Flow 2 dispatch method is available.

Revised: 08/02/2021
